Barco ClickShare control panel is designed to simplify meeting-room collaboration by providing an intuitive, touch-driven interface for video conferencing and room control. The 10.1-inch capacitive touchscreen delivers clear, usable visuals with a 1280 x 800 native resolution, anti-glare and anti-fingerprint surfaces, and a brightness level suited for typical conference environments. Built-in human detection and security features help streamline room readiness while protecting the device, and the compact design fits neatly into modern meeting spaces.

Features

• Responsive 10.1-inch capacitive touchscreen for intuitive meeting control
• Anti-glare and anti-fingerprint display for clear viewing and low maintenance
• Integrated human detection and Kensington-compatible security slot for room awareness and physical protection

Specifications

General

Weight	820 g
Device Type	Control panel
Depth	7.69 cm
Height	18.79 cm
Width	25.45 cm
Built-in Devices	Human Detection sensor
Localisation	Rest of World (excluding United States and India)

Miscellaneous

Compliant Standards

VW-1

Power

Power Device	Power adapter - external
Power Consumption Operational	7.3 watt

Environmental Parameters

Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	0 - 85% RH (non-condensing)

Display

Image Contrast Ratio	1000:1
Native Resolution	1280 x 800
Diagonal Size	10.1"
Image Brightness	300 cd/m²
Monitor Features	Anti-glare, anti-fingerprint, 4-point multi-touch, 60 Hz refresh rate, capacitive touch screen, 80° viewing angle

Input Device

Type	10.1" touchscreen
Features	Security slot (Kensington security lock compatible)
