The Cisco Webex Room Bar - No Radio is a high-quality video conferencing device designed to transform your meetings into a seamless and interactive experience. With its 4-microphone array utilizing beamforming technology, it captures audio with exceptional clarity, ensuring every participant is heard clearly. The device's digital video camera supports both Full HD and 4K resolutions, delivering crisp, detailed visuals that bring your meetings to life. Security is a top priority, and the Room Bar is equipped with AES encryption, Secure Shell (SSH), and TLS protocols to safeguard your communications. Additionally, its advanced video capabilities, including a wide field of view, automatic brightness adjustment, and speaker tracking, automatically enhance focus on the speaker, making meetings more engaging. The Room Bar also excels in network performance, supporting Quality of Service (QoS) standards to provide smooth, uninterrupted video conferencing. Whether for small meetings or large boardrooms, the Cisco Webex Room Bar - No Radio is your solution for reliable, secure, and high-quality video conferencing.

Features

• 4-microphone array with beamforming for clear audio capture
• Supports Full HD and 4K video resolutions for vivid imagery
• Comprehensive security with AES, SSH, and TLS protocols
• 120° horizontal and 95° vertical field of view for broad coverage
• Quality of Service (QoS) for smooth video conferencing performance

Specifications

General

Depth	6.4 cm
Weight	1.5 kg
Width	53.4 cm
Height	8.2 cm
IP Address Assignment	DHCP
Quality of Service	IEEE 802.1Q (VLAN), IEEE 802.1p
Device Type	Video conferencing device
Video Codecs	H.263, H.264, H.239
Enclosure Colour	First light
Bundled with	Cisco Room Navigator-Table Stand
Voice Codecs	G.711, G.722, G.722.1, G.729, AAC-LD, Opus
VoIP Protocols	SIP, H.245, H.323, SRTP
Security	AES, H.323, TLS, IEEE 802.1X, Secure Shell (SSH), SRTP
Network Protocols	NTP, IPv6, HTTP, HTTPS, TLS, Cisco Discovery Protocol (CDP), SSH, DNS, SRTP

Expansion / Connectivity

Interfaces

1 x USB-C / DisplayPort - 24 pin USB-C 1 x audio / video - HDMI input 2 x audio / video - HDMI output 1 x audio - line-in/microphone 1 x USB 2.0 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45

Manufacturer Warranty

Service & Support

Limited warranty - advanced replacement - 1 year

Networking

Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Compliant Standards	IEEE 802.1Q, IEEE 802.1p
Connectivity Technology	Wired
Network / Transport Protocol	NTP, DHCP, IPv6, HTTP, HTTPs, IPv4, DNS
Features	Automatic gain control (AGC), VoIP support, Quality of Service (QoS), DTMF support, URI Dialing, Class of Service (CoS), DiffServ support, 2x2 MIMO technology

Miscellaneous

Mounting Kit	Included
Included Accessories	Table stand
Compliant Standards	CEC 2.0, AES-128, AES-256, Directive 2014/30/EU, Directive 2014/35/EU, Directive 2011/65/EU, Directive 2002/96/EU, NRTL, FCC CFR47 Part 15 B Class A, FCC CFR47 Part 15 C, FCC CFR47 Part 15 E, FCC
Cables Included	1 x HDMI cable - 1.5 m 1 x network cable - 8 m

Power

Power Device	Power adapter - external
Voltage Required	AC 100-240 V (50/60 Hz)
Power Consumption Operational	20 watt

Software / System Requirements

Software Included

RoomOS 11 or later

Environmental Parameters

Min Operating Temperature	0 °C
Max Operating Temperature	35 °C
Humidity Range Operating	10 - 90% RH (non-condensing)

Modem

Digital Signaling Protocol	H.460.18, H.460.19, H.239, BFCP, SIP, H.245, H.323
Data Compression Protocol	H.263, H.264, G.711, G.722, G.722.1, G.729, H.239

Video Input

Digital Zoom	5
Type	Digital video camera (colour) - integrated
Video Modes	1080/60p, 4K/30p
Digital Video Capture Resolution	3840 x 2160, 1920 x 1080
Interface Type	HDMI input, DisplayPort input, HDMI output
Features	120° field of view (horizontal), 1/2.3 CMOS image sensor type, F 2.5 lens aperture, 95° field of view (vertical), face detection, speaker tracking, automatic brightness adjustment, auto white balance, fixed focus, 30Hz frame rate, Acoustic Echo Cancellation (AEC)

Audio Input

Microphone Operation Mode	Beamforming
Type	4-microphone array
