Beheerfuncties

Switch type

Managed

Switch type

Managed

Design

Stapelbaar

Ja

Prestatie

Physical stacking (units)

10

Intern geheugen

8000 MB

Processormodel

ARM Cortex-A72

Type processor

Ja

Processormodel

ARM Cortex-A72

Frequentie van processor

1,8 MHz

Type geheugen

DDR4-SDRAM

Flash memory

32 MB

Energie

AC-ingangsspanning

100 - 240 V

Netvoeding voetnoot

2 field-replaceable, hot-swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A and JL670A.

Stroombron

AC

Vermogenstoevoer inclusief

Ja

AC-ingangsspanning

100 - 240 V

Energieverbruik opmerking

With JL086A PSU: Idle: 133W 100% Traffic Rate: 199W With JL087A PSU: Idle: 138W 100% Traffic Rate: 193W With JL670A PSU: Idle: 140W 100% Traffic Rate: 201W

Stroombron

AC

Vermogenstoevoer inclusief

Ja

Power over Ethernet (PoE)

Totaal Power over Ethernet (PoE)-budget

2880 W

Vermogen per poort Power over Ethernet (PoE)

90 W

Power over Ethernet (PoE)

Ja

Vermogen per poort Power over Ethernet (PoE)

90 W

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten

48

Type basis-switching RJ-45 Ethernet-poorten

5G Ethernet (100/1000/5000)

Aantal moduleslots SPF

8

Console port

RJ-45/USB Type-C

Aantal basis-switching RJ-45 Ethernet-poorten

48

Type basis-switching RJ-45 Ethernet-poorten

5G Ethernet (100/1000/5000)

Aantal moduleslots SPF

8

Console port

RJ-45/USB Type-C

Netwerk

Netwerkstandaard

IEEE 802.3af

10G support

Nee

Netwerkstandaard

IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

10G support

Nee

Data-uitwisseling

Latentie (1 Gbps)

4,24 µs

Latentie (10 Gbps)

1,5 µs

Switchingcapaciteit

880 Gbit/s

Throughput

660 Mpps

Latentie (1 Gbps)

4,24 µs

Latentie (10 Gbps)

1,5 µs

Packet buffergeheugen

8 MB

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)

0 - 45 °C

Overige specificaties

Latentie

1 Gbps: 4.24 µs 10 Gbps: 1.50 µs 25 Gbps: 2.91 µs 50 Gbps: 3.49 µs

Geheugen en processor

Quad Core Arm Cortex™ A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 16 MB Shared Packet Buffer Memory

Aansluitingen

48 x HPE Smart Rate 100 M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port 4 x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W) 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM port

Prestatiebeheer

Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software

Gewicht (imperiaal)

6,71 kg (14.8 lbs)

Afmetingen (B x D x H) (Brits)

43,9 x 442 x 386,1 mm (1.73 x 17.4 x 15.2")

Fan

Switch has two fan tray slots and comes with two fan trays installed. Minimum two fan trays required. Fan trays are field replaceable and hot-swappable. Each fan tray contains two fans.

Gewicht en omvang

Breedte

442 mm

Diepte

385 mm

Hoogte

44 mm

Gewicht

6,71 kg
