Inleiding

Lenovo ThinkSystem DE2000H is a low-cost,hybrid storage system that is designed to provide performance,simplicity,capacity,security,and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options,flexible drive configurations,and enhanced data management features. The ThinkSystem DE2000H is a perfect fit for small offices and remote and branch offices of large enterprises that run a wide range of workloads,including big data and analytics,video surveillance,technical computing,backup and recovery,and other storage I/O-intensive applications.

Specifications

General
Device Type	Hard drive array
Enclosure Type	Rack-mountable - 2U
Localisation	EMEA
Chassis
Installed Devices / Modules Qty	2
Supported Devices / Modules Qty	24
Supported Drives	SAS-3
Storage
HDD Array External Interface	16Gb Fibre Channel,SAS 12Gb/s
Storage Controller
Type	2 x RAID
Interface Type	SAS 12Gb/s
Data Transfer Rate	1.2 GBps
Cache / Buffer Size (Max)	8 GB
RAID Level	RAID 0,RAID 1,RAID 3,RAID 5,RAID 6,RAID 10
Hard Drive
Type	SSD - hot-swap
Capacity	2 x 800 GB
Drive Writes Per Day (DWPD)	3
Expansion / Connectivity
Expansion Bays	24 (total) / 22 (free) x hot-swap - 2.5" SFF
Expansion Slots	2 (total) / 0 (free) x expansion slot
Interfaces	4 x 16Gb Fibre Channel - SFP+ 2 x Ethernet 1000 (management) - RJ-45 2 x serial (management) - 5 pin Micro-USB Type A 2 x serial (management) - RJ-45 8 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644)
Power
Power Device	2 x internal power supply - hot-plug
Max Supported Qty	2
Power Redundancy	Yes
Voltage Required	AC 120/230 V - 50/60 Hz
Power Provided	913 Watt
80 PLUS Certification	80 PLUS Platinum
Dimensions &Weight
Width	44.9 cm
Depth	55.3 cm
Height	8.5 cm
Weight	27.6 kg
Environmental Parameters
Min Operating Temperature	10 °C
Max Operating Temperature	40 °C
Humidity Range Operating	8 - 90% (non-condensing)
